Original MWM Spare Parts
For Maximum Availability and Performance
- Protect the value of your investment with original MWM spare parts.
- Original spare parts are available for the following MWM gas engines and power generator sets: TCG 3016, TCG 3020, TCG 2016, TCG 2020, TCG 2032, G 234, G 604, TBD 604, TBD 616, TBD 620, TBG 441, TBG 604, TBG 620, TBG 632
Original MWM Parts: Maximum Availability and Performance
All parts of MWM gas engines and power generator sets are designed for performance and efficiency. This also applies to our original spare parts, which are governed by the same regulations as the parts we use in the production. Thus, hassle-free operation is a key quality feature of an MWM gas engine. Our spare parts are subject to the same high quality and availability standards. Yes, there are things that cannot be easily substituted!
Protect and preserve the performance of your gas engine with original MWM spare parts in order to ensure reliable operation of your plant.
No matter whether gaskets, gasket kits, spark plugs, cylinder liners, filter inserts, filter cartridges, pistons, piston rings, conrod bearings, compensators, roller tappets, thermocouples, tappets, air filter inserts, lubricant filters, or O rings are concerned, we are the only ones who know our machines down to the last detail and are able to offer maximum performance and useful life.
Preserve the value of your investment
You have invested in the best technology available on the market. Original MWM spare parts are vital for the optimum operation of your power generator set or gas engine in order to ensure the economic success of your system or cogeneration power plant.
We offer spare parts from the original series for the following engines and generator sets:
TCG 3016, TCG 3020, TCG 2016, TCG 2020, TCG 2032, G 234, G 604, TBD 604, TBD 616, TBD 620, TBG 441, TBG 604, TBG 620, TBG 632
Benefits of MWM Spare Parts at a Glance
- 100% MWM, 100% quality
- High reliability, unmatched efficiency, and long useful life
- Designed for optimum engine operation with minimum fuel consumption
- Quick supply of spare parts
- Large spare part warehouse, more than 2 million items on stock
- Always up to date thanks to ongoing further development
- Proven, strictly monitored quality standard
- Quick assistance by our customer and expert service
- Warranty/goodwill services
Spare Parts MWM Gas Engines and Gensets (Selection)
Order number | Spare part | Gas engine / genset | |
---|---|---|---|
12032892 | gasket | TCG 2016, TCG 2020, TCG 3016, TCG 3020, G 604, TBD 604, TBD 620, TBG 604, TBG 620, TCD 2020 | Request an offer |
02931161 | gasket set | TCG 2020, TCG 3020, TBG 620 | Request an offer |
12189925 | filter cartridge | TCG 2016, TCG 2020, CG170, TBD 616, TBG 620 | Request an offer |
12344436 | filter cartridge | TCG 3016 | Request an offer |
12211173 | piston ring set | TBD 604, TBD 620, TBG 620, TCG 2020, TBG 604, TBG 620 | Request an offer |
12420394 | piston | TCG 2016, TCG 2020, TCG 2032, TCG 3016, TCG 3020, TBG 441, TBG 632 | Request an offer |
12453754 | piston | TCG 3020 (steel piston) | Request an offer |
12300185 | compensator | TCG 2016, TCG 2020, TCG 3020, TBD 604, TBG 604, TBG 620, TCD 2020 | Request an offer |
12409722 | air cleaner insert | TCG 2020, TCG 2032, TBG 620 | Request an offer |
12409797 | air cleaner insert | TCG 2020, TCG 2032 | Request an offer |
12420916 | big-end bearing | TCG 2020, TCG 3020, TBD 620, TCD 2020 | Request an offer |
12452423 | connecting rod | TCG 2020, TCG 3020 | Request an offer |
12319561 | connecting rod | TCG 2016, TCG 3016, TCG 616 | Request an offer |
12453142 | roller tappet | TCG 2020, TCG 3020, TBG 620 | Request an offer |
01183301 | o-ring | TCG 2020, TCG 3020, TBD 620, TBG 620 | Request an offer |
12128936 | lubrication oil filter | TCG 2020, G 604, G 234, TBD 234, TBD 604, TBD 616, TBD 620, TBG 234, TBG 604, TBG 616, TBG 620, TCD 2016, TCD 2020 | Request an offer |
12343764 | lubrication oil filter | TCG 2020, G 604, G 234, TBD 234, TBD 604, TBD 616, TBD 620, TBG 234, TBG 604, TBG 616, TBG 620, TCD 2016, TCD 2020 | Request an offer |
12323810 | thermocouple | TCG 2016, TCG 2020 (with TEM), TBG 616, TBG 620 | Request an offer |
12285547 | valve seat ring | TCG 2032, TBG 632 | Request an offer |
12136975 | valve tappet | TCG 2016, TCG 2020, G 604, TBD 604, TBD 620, TBG 604, TBG 620 | Request an offer |
12515552 | prechamber spark plug | TBG 441, TBG 632 | Request an offer |
12285487 | prechamber spark plug | TBG 441, TBG 632 | Request an offer |
12453574 | prechamber spark plug | TCG 2032, TBG 632 | Request an offer |
12453576 | prechamber spark plug | TCG 2032 | Request an offer |
12453564 | prechamber spark plug | TCG 2016 | Request an offer |
12453562 | prechamber spark plug | TCG 2016 | Request an offer |
12344841 | prechamber spark plug | TCG 3016 | Request an offer |
12453572 | prechamber spark plug | TCG 2020 | Request an offer |
12453385 | prechamber spark plug | TCG 2020 | Request an offer |
12453700 | prechamber spark plug | TCG 3020 | Request an offer |
E40 and E40+ maintenance bundle | Check availability by stating the engine number | Request an offer | |
spin-on filter (oil filter/air cleaner) | Check availability by stating the engine number | Request an offer | |
12300136 | ignition cable | TCG 2020, TBD 604, TBD 620, TBG 604, TBG 620 | Request an offer |
12420480 | spark plug | TCG 2016, TCG 2020, TBG 616 | Request an offer |
12275301 | cylinder liner | TCG 2016, TBD 616, TBD 234, TBG 616, TBG 234 | Request an offer |
12300509 | cylinder liner | TCG 2020, TBD 620, TBG 620 | Request an offer |
cylinder heads (new cylinder heads/X-Change cylinder heads) | Check availability by stating the engine number | Request an offer |
Original spare parts from MWM – because every operating hour counts
Efficient Logistics
The logistics center is the central hub for all MWM spare parts. Here, MWM coordinates the worldwide shipping and supply of all plants. Situated just 30 miles from the airport, air freight partners ensure expedited shipping. If necessary, purchase orders received by 5 p.m. are shipped on the same day.
Logistics Center: More Than Two Million Spare Parts on Stock
State-of-the-art warehouse technology ensures maximum supply security. The entire supply chain – order center, warehouse logistics, and scheduling – are unified under one umbrella.
More than two million spare parts – from O-rings weighing only 1 g to crankcases weighing a massive 20 t – are available at the MWM logistics center and can be delivered around the clock.
Frequently Asked Questions (FAQ)
Facts and Figures Logistics Center
Efficiency, reliability, high performance: central spare part logistics in Lorsch, Germany.
Storage space | 12.000 sq ft |
Stock part numbers | Ø 40.000 |
Emergency service | 24/7, 365 days |
Episode 1: Spark Plug Replacement
DATENSCHUTZHINWEIS: Beim Abspielen von Videos gelten die Datenschutzbestimmungen von YouTube. /// PRIVACY NOTE: If you play a video, privacy regulations of YouTube apply.
All language versions of the video on YouTube: DE | EN | FR | ES | CN
Download Video: EN | DE | FR | ES | CN
(5 minutes, high end DVD version, 790 MB, MP4)
Episode 2: Valve Clearance Adjustment
DATENSCHUTZHINWEIS: Beim Abspielen von Videos gelten die Datenschutzbestimmungen von YouTube. /// PRIVACY NOTE: If you play a video, privacy regulations of YouTube apply.
All language versions of the video on YouTube: DE | EN | FR | ES
Download Video: DE | EN | FR | ES
(8 minutes, high end DVD version, 950 MB, MP4)
Episode 3: TPEM Auxiliary Drive Test
DATENSCHUTZHINWEIS: Beim Abspielen von Videos gelten die Datenschutzbestimmungen von YouTube. /// PRIVACY NOTE: If you play a video, privacy regulations of YouTube apply.
All language versions of the video on YouTube: EN | DE | ES | FR | CN | IT
Download Video: EN | DE | ES | FR | CN | IT
(7.5 minutes, high end DVD version, 860 MB, MP4)
Episode 4: TPEM Data Export
DATENSCHUTZHINWEIS: Beim Abspielen von Videos gelten die Datenschutzbestimmungen von YouTube. /// PRIVACY NOTE: If you play a video, privacy regulations of YouTube apply.
All language versions of the video on YouTube: EN | DE | ES | FR | CN | IT
Download Video: EN | DE | ES | FR | CN | IT
(5.5 minutes, high end DVD version, 657 MB, MP4)
Episode 5: Lube oil replacement
DATENSCHUTZHINWEIS: Beim Abspielen von Videos gelten die Datenschutzbestimmungen von YouTube. /// PRIVACY NOTE: If you play a video, privacy regulations of YouTube apply.
All language versions of the video on YouTube: EN | DE | ES | FR | IT | CN
Download Video: EN | DE | ES | FR | IT | CN
(6 minutes, high end DVD version, 722 MB, MP4)
Flyer Logistics
Flyer Logistics Center
All languages on issuu: DE | EN
Download PDF: DE | EN
Service Brochure
This brochure provides an eight-page overview of MWM’s worldwide service, highlighting the company’s experience, training, competence, network, X-Change, spare parts, logistics and planning.
All languages on issuu: DE | EN | FR
Download PDF: DE | EN | FR
